This episode focuses on the technical details of the paint process used in the painting of a Falcon sedan. It also has the Flow coat process in detail.
The work was preformed at PPG training centre at Eastern Creek in Sydney by PPG staff.
The following is the process, products and Equipment.
• Vibrance Hi build primer applied by Howard before going to PPG
• 180-240 dry 150mm 320 Dry
• WOW primer in High Build mode – IN SG6 Spectral Grey 6 (DP621, DP625, DP627)
• Guide coat – Blocked P320 dry – Rub deep into the peel
• Guide coat blocked P400 Dry – Remove P320 scratches
• 150 mm P400 Dry with interface pad on 5mm orbit / Spot prime rub throughs G6 Aersol (PPG Onechoice SUA460-G6) – remove linear / straight scrataches
• Light rub P800 dry with interface pad 150mm sander 5mm orbit – Final check and smooth out G6 aerosol without sanding through
• Clean with water metho cleaner SWX 250 / Followed by prepsol – Two types of contaminants needs two cleaners -R.G water meth removes sweat, prepsol does not.
• SATA X5500 HVLP 1.3 I – 2 Turns out from closed / 1.5 bar / Fan fully open – 1.0 bar for final drop/technique coat – slow thinner / Hardener as per PDS
• SATA X5500 RP 1.3I – 2 Turns out from closed / 2.2 bar / Fan fully open – D800 or DC 516 to seal of base fast hardener / medium thinner – get film hard and ready to sand for flow coat
• Use SATA X5500 RP -Reduced Pressure if using piston compressor – Atomises at a lower / reduced pressure vs HVLP – High Volume Low Pressure – Good with Screw compressor
• Flow coat Preparation
• Block clear P400 Dry
• 150 MM P400 no interface /P800 dry with interface followed by Abralon P1000 damp (clean water or metho water
• Clean with water metho cleaner SWX 250 / Followed by prepsol – Two types of contaminants needs two cleaners -R.G water meth removes sweat, prepsol does not.
• Clear coat – Vibrance Custom clear VCC580 mixed 2:1:0,9 –SATA x5500 RP – 1.2 Nozzle – 1.5 Turns out from closed / 2.6 bar / Fan fully open – Finer atomisation
